Product Description:
Thermal Break Strip is a highly durable and cost-effective product for thermal insulation. It features a black color, temperature resistance of ≥240℃, and is made of PA66GF25, a highly heat-resistant material. The length of the strip can be customized according to your needs. We accept payments from T/T and Western Union. Our thermal broken strip is designed to offer maximum insulation for your applications, and make sure that the heat transfer is minimized. It is also highly flame retardant and non-toxic, making it the perfect choice for applications requiring thermal insulation.
Features:
- Product Name: Thermal Break Strip
- Material: PA66GF25
- Shape: Rectangle/ Square/ Oval/ Customized
- Thickness: Customized
- Application: Doors/ Windows/ Furniture/ Machinery
- Package: Customized
They provide a better thermal insulation
They need lesser use of metals
The polyamide strips are cost-effective
They are easy to create thermal barriers with
They help in resources to be conservedand can reduce operating costs
They ensure maximum stability of the structure
They are more than effective in resisting condensation
They don’t require any special handling or fabrication
Technical Parameters:
| Item | Unit | GB/T 23615.1-2009 | PW-Technical specification |
| Density | g/cm3 | 1.3±0.05 | 1.28-1.35 |
| Linear expansion coefficient | K-1 | (2.3-3.5)×10-5 | (2.3-3.5)×10-5 |
| Vicat softening temperature | ºC | ≥230ºC | ≥233ºC |
| Melting point | ºC | ≥240ºC | ≥240ºC |
| Testing for tensile cracks | - | No cracks | No cracks |
| Shore hardness | - | 80±5 | 80-85 |
| Impact strength(Unnotched) | KJ/m2 | ≥35 | ≥38 |
| Tensile strength(longitudinal) | MPa | ≥80a | ≥82a |
| Elasticity modulus | MPa | ≥4500 | ≥4550 |
| Elongation at break | % | ≥2.5 | ≥2.6 |
| Tensile strength(transverse) | MPa | ≥70a | ≥70a |
| High temperature tensile strength(transverse) | MPa | ≥45a | ≥47a |
| Low temperature tensile strength(transverse) | MPa | ≥80a | ≥81a |
| Water resistance tensile strength(transverse) | MPa | ≥35a | ≥35a |
| Aging resistance tensile strength(transverse) | MPa | ≥50a | ≥50a |
1. Sample water content less than 0.2% by weight.
2. Norm laboratory condition:(23±2)ºC and (50±10)% relative humidity.
3. The specifications marked with "a" only applies to I-shape strip otherwise, the specifications concluded between supplier and buyer through consultation, shall be written in contract or purchase order.
Storage:
Polyamide thermal breaks are extruded in dry state but they absorb moisture from the environment after the production as time passes. Moisture level depend the following conditions:
- Ambient temperature
- Ambient humidity
- Storage period
During the summer time, when the temperature and humidity in storage area are higher than usual, the insulating profiles absorb more moisture than in the remaining seasons, even stored properly.
Support and Services:
1. introduce products in detail
2. recommend suitable solutions
3. provide with reference information
1. provide with layout and engineering conditions
2. inform the processing status
3. offer related documents
1. provide installation, commissioning and training
2. offer spare parts
3. Provide with necessary technical support
Package & Delivery:
Packaging details:For all specifications/shapes, they could be packaged in linear, the length will be 6 meters, or customized.
For the Shape "I", "C", and some simple shapes, they can be packed in rolls. 400-600 meters/roll.
Delivery details: shipped in 15-20 working days after payment
